Discover the full potential of our flight sim.
A 6-axis full-motion flight simulator platform with an additional gearbox on each motor, the H6 flight version is designed for the slow, precise movements that fixed-wing and helicopter simulations demand. Where the racing version relies on direct-drive motors, this model adds SFU gearing to each axis for extra smoothness - a meaningful difference when reproducing the gradual attitude changes and subtle turbulence of real flight.
The rig covers all six degrees of freedom: heave, roll, pitch, surge, sway, and yaw. All controllers - yoke, pedals, joystick, and monitor - move with the seat as a single unit, simulating g-forces through muscle pressure points. The platform also works for helicopter simulations and can double as a racing rig without any loss of capability.
SimRacingStudio software drives the motion using live aircraft telemetry, reproducing runway bumps, turbulence, vibrations, and collision forces. Technical specs include a 17-degree range of motion, 50 cm/s (86 deg/s) actuation speed, and 28 N/m torque per motor. DOF Reality has manufactured motion platforms since 2014 and includes a 1-year full warranty and 24/7 support with every unit.
Compatible across all major platforms and dozens of racing and flight games.
H6 ships from Poland. Delivery to the US takes approximately 3-4 weeks. The platform is fully assembled and tested, then disassembled for transport. The platform ships in two boxes with all reassembly tools and hardware included.
Features
- True 6-axis flight motion - Pitch, Roll, Yaw, Surge (acceleration/deceleration), Sway (lateral), and Heave (vertical: turbulence, G-loads)
- True lateral and longitudinal motion - Actual body displacement for sway and surge, not just tilting
- Full cockpit motion - HOTAS, yoke, throttle, and all controls move as one unit
- Rigid metal motor covers included
- HOTAS and yoke compatible - HOTAS Mounts Kit and HoneyComb A+B adapter available separately
- VR compatible - Full motion compensation support
- SimRacingStudio license included
- 27+ flight and helicopter titles supported - MSFS 2024, DCS, X-Plane 12, IL-2 Sturmovik, War Thunder, Elite Dangerous, and more
- Trusted by NASA, the US Navy, and the Air Force
- 440 lbs / 200 kg pilot weight capacity
In The Box
- Rigid metal motor covers
- Rigid metal rig (normal and F1 pose)
- Mounts for seat or sliding rails
- Integrated power drive motors (pre-installed)
- 100-240V control unit with USB
- SimRacingStudio license
- Quick assembly tools
- 1-year full warranty
Please note: seat, VR headset, and flight controls (HOTAS, yoke, pedals) are sold separately.
Specifications
| Degrees of Freedom | 6 DOF (Pitch, Roll, Yaw, Surge, Sway, Heave) |
| Full Platform Motion | Yes (entire rig moves) |
| Range of Motion | 17° |
| Speed | 50 cm/s (86°/s) |
| Torque | 28 N/m |
| Acceleration | 0.5G all directions |
| Power Consumption | 1,500 Watt (peak) |
| Pilot Weight Capacity | 440 lbs / 200 kg |
| Footprint | 4×5 ft, 2 ft H (120×150 cm, 60 cm H) |
| Box Weight | 2 boxes: 133 lb + 144 lb |
| Compatible Software | SimRacingStudio (included); MSFS 2024, DCS, X-Plane 12, IL-2, 27+ titles |
| Warranty | 1 year full warranty |
| Shipping Origin | Warsaw, Poland |
| Estimated US Delivery | 3-4 weeks from order |
