DOF Reality 4-Axis Hero (H4) - flight/heli

All DOF Reality products incur US import tariffs which customers must pay directly to US Customs. Expected tariffs range from 10-20% of the sale price, though rates fluctuate and cannot be guaranteed due to changing tariff policies. We apologize for this uncertainty which is beyond our control.

The H4 Hero is designed to deliver real physical sensations that home simulators could not provide before. It is the only at-home motion simulator with true 4-axis movement - including Heave - letting you feel vertical g-forces, turbulence, jumps, and changes in acceleration with high precision.

This flight-configured version of the H4 includes Xtra Smooth Gearing alongside the SFU (screw-type linear actuators), producing fluid, continuous motion that suits the sustained control inputs of fixed-wing and helicopter flight simulation. Built on DOF Reality's experience developing motion simulators since 2014, the platform brings 4-axis motion realism into a compact home setup.

The floor footprint measures 3 x 5.2 ft (100 x 150 cm) with a height of 2 ft (60 cm), making it suitable for home use without a large dedicated room. The frame is constructed from high-strength European steel. All controls - seat, flight stick, rudder pedals, and yoke - move together as a single unit, delivering force feedback through body pressure points rather than visual cues. The platform integrates with flight controls and all major VR headsets.

4-axis movement covers Pitch, Roll, Yaw, and Heave. Key specs: 20-degree range of motion, 50 cm/s (86 deg/s) actuation speed, 25 Nm torque, 0.7G traction and 0.5G lateral acceleration, 750-watt peak power draw, and a supported pilot weight of 330 lbs (150 kg). The platform carries a full 1-year warranty and is upgradeable to 6-axis.

Compatible across all major platforms and dozens of racing and flight games.

H4 Hero ships from Poland. Delivery to the US takes approximately 3-4 weeks. The platform is fully assembled and tested, then disassembled for transport. The platform ships in two boxes with all reassembly tools and hardware included.

Features

• True 4-axis flight motion - Pitch (nose attitude), Roll (bank), Yaw (skidding/sideslip), and Heave (vertical: turbulence, bumps, altitude changes)
• SFU Screw-Driven Force Unit and Xtra Smooth Gearing - Optimized for the slow, continuous, fluid motion characteristic of flight simulation
• Full cockpit motion - HOTAS, yoke, throttle, seat, and all controls move together as a single unit
• High-strength European steel construction
• HOTAS compatible - HOTAS Mounts Kit available separately; joystick mounts center or side
• HoneyComb Alpha Bravo compatible - Adapter available separately for yoke and throttle
• VR compatible - Full VR support with motion compensation for MSFS, DCS, X-Plane
• SimRacingStudio license included
• 27+ supported flight and helicopter titles
• Upgradeable to H6r (6-Axis)
• 440 lbs / 200 kg pilot weight capacity

In The Box

• Rigid metal rig (normal and F1 pose)
• Mounts for seat or sliding rails
• Integrated power drive motors with SFU and Xtra Smooth Gearing (pre-installed)
• 100-240V control unit with USB
• SimRacingStudio license
• Quick assembly tools
• 1-year full warranty

Please note: seat, VR headset, and flight controls (HOTAS, yoke, pedals) are sold separately.

Specifications

Manuals
